“ Y ” type Strainer

Briflon® High quality fully FEP / PFA Lined , One pc. Design Cast ductile iron , Bolted Cover, Uni-directional Flanged End “ Y “ type Strainer. PFA Lined body and the corrosion resistant ETFE filter screen inserted between the two PTFE basket provides excellent filtration of the process media with outstanding corrosion resistant.



  • Cross-Section Drawing
  • Design Features & Benefits
  • Dimension (MM) & Test Pressure
  • Lining Specification
  • Advantage
SR.NO. PART NAME MATERIAL
1 STRAINER BODY ASTM A395 DUCTILE IRON + PFA/FEP LINING
2 END COVER ASTM A216 GR.WCB
3 DRAIN PLUG PTFE
4 HEX. HD BOLT ASTM A193 GR.B7
5 FILTER ELEMENT PTFE

DIMENSION(MM)-150#

SIZE (NB) A
25 190
40 260
50 284
65 298
80 348
100 415
150 508

TEST PRESSURE

BODY (HYDRO) 20 Kg/cm2g (Before Lining)
SEAT (HYDRO) 10 Kg/cm2g (Before Lining)
TYPE PFA/FEP
SPARK TEST 15 K.V D.C
THICKNESS 3.0 MM OVER ALL WETTED PARTS
